Lab Pumps
Rocker 410 Oil Free Vacuum Pump
◆ No air pollution, maintenance free
◆ Prote™ overflow protection
◆ Moisture trap with filter cartridge
◆ Vacuum regulator
◆ Thermal protection device
◆ CE certification
◆ CSA certification
◆ IP 30 protection
◆ RoHS certification
- Instruction
- Specification
- Download
Oil Free Vacuum Pump / Dry Vacuum Pump Features:
◆ No air pollution, maintenance free
Rocker series lab vacuum pumps are driven by Piston, without the need of lubricant, regular oil changes and maintenance; with no oil pollution.
◆ Moisture trap with filter cartridge
Rocker 410 lab vacuum pump is equipped with filter cartridge at the air inlet to filter particle and moisture to prolong the life of pump.
◆ Vacuum regulator
Rocker series lab vacuum pumps are equipped with vacuum regulator to adjust vacuum.
◆ Thermal protection device
Every motor of Rocker series lab vacuum pumps has a built-in thermal protection device to shut off the pump automatically when overheated and then resume working when the temperature cools down.
◆ Prote™ overflow protection <ONLINE SHOW!>
Rocker 410 lab vacuum pump is equipped with Prote™ overflow protection which can prevent a large amount of liquid from being sucked into the pump.
Oil Free Vacuum Pump / Dry Vacuum Pump Video
Oil Free Vacuum Pump / Dry Vacuum Pump International Certificates:
◆ CE certification
◆ CSA certification
◆ IP 30 protection
◆ RoHS certification
Oil Free Vacuum Pump / Dry Vacuum Pump Applications
◆ Suspended solid test
◆ Vacuum filtration
◆ Microbiological test
◆ Air sampling
Oil Free Vacuum Pump / Dry Vacuum Pump Ordering Information :
Product Part Number | Product |
◆ 167410-11 ◆ 167410-22 |
Rocker 410, Oil Free Vacuum Pump AC110V, 60Hz Rocker 410, Oil Free Vacuum Pump AC220V, 50Hz |
Rocker410 | 110V/60Hz | 220V/50Hz |
Max. power | 100W | 80W |
Max. current | 1.0A | 0.4A |
Max. vacuum | 25 mbar | |
Max. flow rate | 23 L/min | 20 L/min |
Motor rotation speed | 1750 RPM | 1450 RPM |
Horse power | 1/6 HP | |
Noise level | 52 dB | |
Hose barb | ID8 (5/16 inch) | |
Net weight | 5.2Kg | |
Dimension (LxWxH) | 31 x 13.5 x 20.4 cm | |
Vacuum Regulator | Yes | |
Overflow protection | Yes | |
Thermal protection | Yes |
