Lab Filtration
SolarVac 600 โ MS
Rotary Multi-Branch Manifold
- Instruction
- Specification
- Tech Support
SolarVac Multi-Branch Manifold Features
- Rotary design
Turn the funnels and add samples at same position and prevent cross-contamination. - Save 60% space
Compared to conventional linear manifolds, SolarVacโs rotary design saves 60% of space and fits better in laminar flow hoods. - Easy tracking
Each funnel position is marked clearly with numbers, making tracking easy and effortless. - Durable and autoclavable
The wetted parts of SolarVac manifold are made of SS316 and silicone which is durable and autoclavable. - Individual control valve
Control feeds of each funnel individually.
SolarVac Multi-Branch Manifold Videos
SolarVac Multi-Branch Manifold Applications
SolarVac Multi-Branch Manifold Ordering Information
Product Number | Description |
186600-01 | SolarVac 600 โ MS |
200300-01 | MF 3, Magnetic Filter Holder, 300 mL |
200500-01 | MF 5, Magnetic Filter Holder, 500 mL |
200300-01-P | MF 3 Pro, Magnetic Filter Holder, 300 mL |
200500-01-P | MF 5 Pro, Magnetic Filter Holder, 500 mL |
SolarVac 600 โ MS Filtration Manifold Specification
Specification โธ Number of branch: 6 โธ Filter diameter: Dependent to filter holders โธ Hose barb: ID8 โธ Net weight: 8.6 Kg โธ Dimension: ฮฆ34 x 18 cm |
Material โธ Body: SS304 โธ Control valve: SS316 โธ Adaptor: SS316 โธ Membrane support: SS316 โธ Hose barb: SS316 โธ Knob: Aluminum โธ Tubing connection: Silicone |
